The RH56BFX Series is a high‑speed 5‑finger dexterous hand designed for applications where rapid, responsive manipulation is critical. Available in left‑hand (RH56BFX‑2L) and right‑hand (RH56BFX‑2R) configurations, as well as versions with an integrated 2‑DOF wrist (RH56BFXW‑2L / 2R), the BFX Series delivers industry‑leading articulation speeds while maintaining compact, lightweight construction.
Key Features
-
Ultra‑High Speed Articulation – Thumb lateral rotation speed reaches 235°/s, thumb bending speed 150°/s, and four‑finger bending speed reaches an exceptional 570°/s – among the fastest in its class.
-
Compact and Lightweight – Weighing only 540g (standard) or 650g (with wrist), the BFX Series minimizes payload burden on robotic arms.
-
Integrated Force Sensing – Built‑in force sensors provide real‑time feedback for precise, adaptive gripping.
-
Power‑Off Self‑Locking – Maintains position when power is disconnected; no re‑homing required on power‑up.
-
Optional 2‑DOF Wrist – Wrist‑equipped version (DFXW) adds ±27° yaw and ±22° pitch, with load torque rating of 2 N·m (excluding hand weight).
-
RS485 Communication – Simple, reliable integration with most control systems.
Technical Specifications
| Parameter | RH56BFX-2L / 2R | RH56BFXW-2L / 2R |
|---|---|---|
| Model | LH: RH56BFX-2L / RH: RH56BFX-2R | LH: RH56BFXW-2L / RH: RH56BFXW-2R |
| Degrees of Freedom | 6 | 6 + 2 (wrist) |
| Number of Joints | 12 | 12 (hand) + 2 (wrist) |
| Weight | 540g | 650g |
| Operating Voltage | DC 24V ±10% | DC 24V ±10% |
| Static Current | 0.09A | 0.1A |
| Peak Current | 2A | 2A |
| Repeat Positioning Accuracy | ±0.20 mm | ±0.20 mm |
| Thumb Fingertip Force | 6N | 6N |
| Four‑Finger Fingertip Force | 4N | 4N |
| Force Resolution | 0.50N | 0.50N |
| Thumb Lateral Rotation Range | >65° | >65° |
| Thumb Lateral Rotation Speed | 235°/s | 235°/s |
| Thumb Bending Speed | 150°/s | 150°/s |
| Four‑Finger Bending Speed | 570°/s | 570°/s |
| Wrist Yaw Movement | — | ±27° |
| Wrist Pitch Movement | — | ±22° |
| Wrist Load Torque | — | 2 N·m (excluding hand) |
| Control Interface | RS485 | RS485 |
Key Application Scenarios
| Scenario | Application Description |
|---|---|
| High‑Speed Sorting & Picking | Rapid grasping and release for logistics, warehousing, and light manufacturing |
| Prosthetic & Assistive Robotics | Lightweight, high‑speed response for prosthetic hand applications |
| Agile & Mobile Robots | Low weight and high speed ideal for drones, legged robots, and mobile platforms |
| Educational & Research Labs | Grasp planning, high‑speed manipulation studies, force control algorithms |
| Teleoperation & Remote Control | Paired with haptic gloves for responsive remote manipulation |
Product Highlights
-
Fastest in its class – 570°/s four‑finger bending speed
-
Ultra‑lightweight – 540g (standard) / 650g (with wrist)
-
Integrated force feedback – Real‑time force sensing for precise control
-
Power‑off self‑locking – No homing required on power‑up
-
Optional 2‑DOF wrist – Expands workspace with ±27° yaw and ±22° pitch
-
RS485 communication – Simple, reliable integration
